Kaixin KX5600 VET

Kaixin KX5600 Portable Veterinary Ultrasound

Description

FEATURE

– 10.4 high resolution color LED backlight display, with high contrast and wide viewing angle.
– OB Measurement: EDD and GA for Bovine, equine, ovine, canine, feline, goat, swine and llama.
– Adjustable LCD screen is more ergonomic, allowing you more comfortable.
– Menu operation system, with different languages according to requirement including Spanish, English, French, Russian and Portuguese.
– Unique One-key-light keyboard function for black room use.
– OB measurement including: Cattle, dogs, horses, cats, goats, camels and sheep and pre-gestational age birth.
– One-key store: concise and practical.
– One-key review: fast, practical image review function.

PARAMETER

– 10.4 high resolution color LED backlight display, with high contrast and wide viewing angle.
– Adopt ARM7 embedded control system +FPGA signal processing system + well selected ultrasound hardware system, all make the unit more stable.
– Menu operation system, with different languages according to requirement including Spanish, English, French, Russian and Portuguese.
– Two probe sockets, auto-identify different optional probe.
– Body marks 1.General 2. Bovine 3.Canine 4.Equine 5.Feline 6.Cardio 7. Swine, total 27 kinds body marks indicating probe position.
– Display mode?B?2B?4B ?B/M?M.
– Adjustable depth: 10 grades, max depth to 236mm.
– Gain 0 127dB.
– Contrast 27 90dB.
– Gray scale 256.
– 8 steps intelligent TGC.
– 8 kinds pseudo colors.
– Image storage: 4G hard disk to permanently store about 5000 frames images.
– Cine loop 256 frames.
– Puncture guide function with 2 correctable puncture guiding lines(adjustable angle & position).
– The gravel software package with real-time position line measurement.
– Normal measurement: Distance, circumference, area (trochoid?or ellipse), volume, etc.
– Cardio measurement Depth, slope, heart rate, cycle.
– OB measurement including: Cattle, dogs, horses, cats, goats, camels and sheep and pre-gestational age birth.
– Other measurement: pig meat factor measurement.
– OB report function.
– One-key store: concise and practical.
– One-key review fast, practical image review function.
– One-key Print.
– One-key Transfer the current frozen image to net workstation to complete its image text report and print directly.
– Concise and practical, easy operation. The system includes network workstation to complete data & report management (You don?t need to invest more to buy extra ultrasound working station).
– Unique One-key-light keyboard function for black room use.
– Display brightness adjustable.
– Dual TV output: PAL/NTSC, can connect video printer when necessary.
– Power supply 100-240V 1.2-0.6A frequency 50-60Hz.
– Power supply adaptor output?DC12.8V 3.0A.
– Main unit weight 4.5kg (without accessories).
– Main unit dimension 256 150 326mm (L W H).

Standard Configuration

– Main unit.
– 6.5MHz linear rectal probe.
– Power supply adaptor.
– Reticle.
– Two probe sockets.

Optional Configuration:

– Battery charger.
– Li-battery: HYLB-1614 11.1V-4400mAh 48.84Wh.
– Trolley.
– Video printer (UP-897MD).
– Ethernet Switch.

Optional Probes:

– 4.0MHz convex rectal probe.
– 6.5MHz micro-convex probe for small animals.
– 3.5MHz linear probe for eye muscle.
– 3.5MHz convex probe.
– 7.5MHz linear probe.
